SSR1 Single-Stud Raman Test Mold for Solid-State Batteries
$415.00
| Size |
Single Stud Raman Test Die-Complete Set |
|---|
SSR1 Single-Stud Raman Test Mold for Solid-State Batteries
A compact, pressure-stabilized Raman testing fixture designed for
in-situ and operando Raman spectroscopy in solid-state battery research.
- High-transparency quartz optical window
- Excellent UV, visible, and IR light transmission
- UV-grade performance for short-wavelength Raman excitation
- Electrical insulation and chemical inertness
- Single-stud compression for improved pressure stability
- Uniform force distribution across the test stack
- High thermal stability under laboratory conditions
- Suitable for repeated electrochemical–Raman experiments
| Product Name | Single-Stud Raman Test Mold (SSR1) |
| Inner Diameter | Φ6–10 mm (customizable) |
| Optical Window | High-transparency quartz window |
| Main Materials | No.4 steel frame, PA insulating components |
| Version | Pressure-stabilized design |
| Operating Condition | Room-temperature laboratory operation |
The SSR1 Raman test mold is suitable for solid-state batteries,
solid electrolytes, and interfacial studies requiring
simultaneous mechanical compression and Raman spectral acquisition.
Custom dimensions and configurations are available upon request.
