RSP1 Round/Square Powder Pellet Press Die - C Split Chrome Steel Lab Mold

RSP1 Round/Square Powder Pellet Press Die – C Split Chrome Steel Lab Mold

Price range: $548.00 through $640.00

Size	Circular Tablet 10mm-Complete Set , Side length 10mm square compression tablets-complete set

Add to wishlist

SKU: RSP1 Category: Solid-State Battery Molds

Description

Potentiolab • Laboratory Press Dies

Split-Type Round / Square Powder Pellet Press Die

A split-type powder pellet press die designed for efficient pellet forming and easy demolding in laboratory applications.
Compared with conventional ejector-pin molds, the split design releases the pellet by laterally separating the mold sections,
reducing mechanical stress and lowering the risk of edge chipping or cracking. It is especially suitable for fragile, brittle, or high-hardness materials.

Split Design
Easy Demolding
Chrome Steel

Split-type round and square powder pellet press die

Split chrome steel lab mold for powder pellet pressing

Key Features

Split-petal design for efficient demolding
Reduces pellet damage and edge chipping
Suitable for fragile or high-hardness materials
Improves release performance compared with ejector-pin molds
Precision-machined for stable laboratory use

Material & Process

Material: Chrome Steel
Process: High-Temperature Heat Treatment (Quenching)
Type: Round Pellet Press Die
Optional Form: Square Pellet Press Die

Product Name	Split-Type Round Powder Pellet Press Die
Pellet Diameter	φ10 mm
Outer Dimensions	60 × 85 mm
Material	Chrome Steel
Available Types	Round Pellet Press Die, Square Pellet Press Die
Manufacturing Process	High-Temperature Heat Treatment (Quenching)

Traditional pellet molds often rely on ejector pins to push the formed tablet out of the cavity, which can easily cause
edge cracking or breakage, especially when pressing brittle materials. This split-type pellet press die releases the pellet
by laterally opening the mold sections, minimizing stress during demolding and improving the success rate of finished pellets.
It is suitable for laboratory powder compaction, material research, and sample preparation where clean pellet release is important.
